Detail
| Product Characteristics | ||||
| Performance | Test Criteria | Test Conditions | Unit | Typical |
| value | ||||
| Physical properties | ||||
| Melting index | ASTM D1238 | 300 ºC/1.2 Kg | g/10min | 20 |
| Molding shrinkage | ASTM D955 | - | % | 0.5-0.7 |
| Water absorption rate | ASTM D570 | 23 °C, 24h | % | 0.2 |
| Density | ASTM D792 | - | g/cm ³ | 1.2 |
| Mechanical properties | ||||
| Tensile strength | ASTM D638 | 50mm/min | MPa | 65 |
| Tensile modulus | ASTM D638 | 1mm/min | MPa | 2300 |
| Yield stress | ASTM D638 | 50mm/min | MPa | 65 |
| Elongation at break | ASTM D638 | 50mm/min | % | 110 |
| Bending strength | ASTM D790 | 2mm/min | MPa | 90 |
| Flexural modulus | ASTM D790 | 2mm/min | MPa | 2200 |
| Notched impact | ASTM D256 | 23ºC | KJ/m2 | 65 |
| strength of | ||||
| cantilever beam | ||||
| Thermal properties | ||||
| Thermal distortion | ASTM D648 | 1.82 MPa; 3.2 mm | ºC | 127 |
| temperature | ||||
| Vicat softening | ASTM D1525 | 120 °C/h; 50N | ºC | 147 |
| point | ||||
| Combustion performance | ||||
| Flame retardant | UL 94 | 3mm | - | HB |
| rating | ||||
| Revision Date: 20190827 1/2 Version No.: V 2.0 | ||||
| Optical properties | ||||
| Haze | ASTM D1003 | 3mm | % | - |
| Light transmittance | ASTM D1003 | 3mm | % | - |
| (visible light) | ||||
| 850nm light | ASTM D1003 | 2mm | % | 90 |
| transmittance | ||||
| 940nm light | ASTM D1003 | 2mm | % | 90 |
